| Items | Parameters and configuration
Model:UPS-20JT(C) | Remarks |
| Concrete jet pump | Manufacturer | Anhui Jarlo Construction Machinery Co., Ltd. | |
| Type | Piston pumping system | |
| Capacity(m3/h) | 20m3/h | |
| Concrete specification | slump | 12~18(cm) | |
| Max.Aggregate size | 25(mm) | |
| Shotcrete aggregate particle size | Max. 25(mm) | |
| Concrete delivery valve type | S Pipe valve | |
| Concrete pumping pressure | 7.5(MPa) | |
| Concrete bore size × stroke | φ160*800(mm) | |
| Main cylinder diameter | 90(mm) | |
| Hopper volume | 0.4(m3) | |
| Hopper loading height | 1.25(m) | |
| Vibrator | 380V | |
| Boom of concrete spraying machine | Manufacturer | Anhui Jarlo | |
| Structure type | Main arm rotation, spray arm pitch + telescopic | |
| Maximum effective spray range | Upward | 10(m) | |
| Forward | 8(m) | |
| Downward | 3(m) | |
| Width | 16(m) | |
| Boom rotation angle | 360° | |
| Boom pitch range | (Upward 64° / Downward 40° ) | |
| Axial rotation range of nozzle sea | 360(°) | |
| Axial swing range of nozzle seat | 240(°) | |
| Nozzle swaying angle+movement | 8°*360° Rotation | |
| Operation | Dual control: 100 meters wireless remote control + 16 meters wired | |
| Remote control system | JARLO | JARLO |
| Boom balance valve | Italian | |
| Conveying pipeline(mm) | Steel pipe:80 Hose:76 | |
| Conveying pipeline cleaning | Water washing + air washing | |
| Hydraulic system | Main oil pump | Type and manufacturer | Electric proportional piston pump PUSH | |
| Rated pressure | 28(MPa) | |
| Flow | 110(L/min) | |
| Main pump valve | Taiwan | |
| Swing cylinder valve | Taiwan | |
| Auxiliary oil pump | Type and manufacturer | Piston pump, | |
| Rated pressure | 28(MPa) | |
| Flow | 41(L/min) | |
| Air compressor | Nominal volume flow | 7.3(m3/min) | |
| Motor nominal power | 37(kw) | |
| Exhaust pressure(Mpa) | Rated pressure0.55MPa | |
| Accelerator automatic batching system | Manufacturer | JARLO | |
| Type | Hose pump | |
| Flow | 0~800(L/h) | |
| Delivery pressure | 10(bar) | |
| Accelerator flow valve | American Hydraforce | |
| Accelerator tank volume | 500 L | |
| High Pressure washing pump | Manufacturer | Black cat 1812 | |
| Max. Output pressure (MPa) | 15 | |
| Output flow(L/min) | 15 | |
| Water tank volume(L) | 175 | |
| Electrical System | Motor protection level | IP55 | |
| Safety protection | Leakage protection, safety grounding | |
| Controller form and manufacturer | Special controller, Germany IFM | |
| Low voltage control electrical appliance brand | Schneider | |
| Cable | Cable drum drive method | Hydraulic drive | |
| Cable specifications | 3*50+1*16 | |
| Cable length | 100m | |
| External power requirements | Alternating current 380V,200KVA | |
| Other configurations | Working lamp | LED | |
| Hydraulic legs | Available | |
| DOC+CDPF | Available | |
| Automatic fire extinguisher | Available | Optional |
